C66 Fingerprint Scanner (Android 11)

C66 Fingerprint Scanner (Android 11)

Biometric Handheld Terminal with Fingerprint Recognition

Chainway C66 is a biometric handheld terminal. It is based on the Android 11 and equipped with Qualcomm Octa-core CPU, 5.5″ high-definition touch screen, large capacity detachable battery, supports fast charging, and various accessories. Additionally, it has integrated high-performance biometric functions to support fingerprint identification, and face recognition applications with high security and flexibility. Also, it can be equipped with barcode scanning, NFC, and other functions, which are widely used in census, national election, security, national defense,etc.

GET QUOTE
Features
Android 11
QC3.0 Quick Charge and RTC
5.5" IPS Display
Qualcomm 1.8GHz Octa-core
RAM+ROM: 3+32GB/4+64GB (optional)
Functions
Fingerprint Recognition
Barcode Scanning (Optional)
13MP Autofocus Camera
GPS, BeiDou，GLONASS

SPECIFICATIONS

Physical

  • Dimensions: 160.0 x 76.0 x 17.0 mm / 6.3 x 2.99 x 0.67 in.
  • Weight: 297 g / 10.47 oz. (device with battery)
  • Display: 5.5-inch high definition full display (18:9), IPS IGZO 1440 x 720
  • Battery: Removable main battery (normal version:4420 mAh ; Android 11.0 with fingerprint / built-in UHF / volume measurement version: 5200mAh )5200 mAh optional pistol battery, support QC3.0 and RTCStandby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h)Continuous use: over 12 hours (depending on user environment)Charging time: 2.5 hours (charge device by standard adaptor and USB cable)
  • Touch Panel: Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
  • Vibrator: USB Type-C, USB 3.1, OTG, extended thimble
  • Card Slot: 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
  • Keypad: 1 power key, 2 scan keys, 2 volume keys
  • Sensors: Accelerometer sensor, light sensor, proximity sensor, gravity sensor
  • Audio: 2 microphones，1 for noise cancellation；1 speaker；receiver

Platform

  • Operating System: Android 11; GMS, 90-day security updates, Android Enterprise Recommended, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported. Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility
  • Sdk: Chainway Software Development Kit
  • Language: Java
  • Tool: Eclipse / Android Studio
  • Cpu: Qualcomm Snapdragon™ 662 Octa-core, 2.0 GHz
  • Ram+Rom: 3 GB + 32 GB / 4 GB + 64 GB
  • Expansion: Supports up to 128 GB Micro SD card

Wireless

  • Wlan: Support 802.11 a/b/g/n/ac/ax-ready/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6, 5G PAFast roaming: PMKID caching, 802.11r, OKCOperating Channels: 2.4G(channel 1~13), 5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132, 136,140,144,149,153,157,161,165), Depends on local regulationsSecurity and Encryption: WEP, WPA/WPA2-PSK(TKIP and AES), WAPI-PSK—EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc
  • Wwan: 2G: 850/900/1800/1900 MHz3G: CDMA EVDO: BC0WCDMA: 850/900/1900/2100MHzTD-SCDMA: A/F(B34/B39)4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41
  • Bluetooth: Bluetooth 5.1
  • Vo-Lte: Support Vo-LTE HD video voice call
  • Gnss: GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Environmental

  • Operating Temp: 4oF to 122oF / -20 ℃ to +50 ℃
  • Storage Temp: -40oF to 158oF / -40 ℃ to +70 ℃
  • Humidity: 5% RH – 95% RH non condensing
  • Drop Specification: Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range Multiple 2.4 m / 7.87 ft. drops (at least 20 times) to the concrete after installed rubber bumper
  • Tumble Specification: 1000 x 0.5 m / 1.64 ft. falls at room temperature
  • Sealing: IP65 per IEC sealing specifications
  • Esd: ±15 KV air discharge, ±8 KV conductive discharge

Accessories

  • Accessories: Wrist Strap; Rubber Bumper; Charging Cradle

Other

  • Speaker: Sound, LED indicator, vibrator
