C75 Mobile Computer with Printer

Mobile Efficient Receipt Printing

Chainway C75 is a handheld computer with large display and thermal printing. It supports various type of printing cores and enables quick printing of receipt. The built-in dual slots for PSAM cards help in easy encryption of data. And it boasts superb performance, and supports optional NFC, barcode scanning, etc. This mobile computer can be used in various sectors like retail, parking and so forth.

GET QUOTE

Features

Android 11

8000mAh Built-in Battery

5.2'' IPS 1080P Screen

Cortex-A53 Octa-core 2.3 GHz , IP54 Sealing

IP54 Sealing

Functions

Barcode Scanning (Optional)

NFC

13MP Autofocus Camera

Dual-band WIFI

Secure PSAM

Thermal Printing

SPECIFICATIONS

Physical

Dimensions: 186.89*83.99*35.04-49.49mm
Weight: 507g/17.88oz
Display: 5.2” IPS LTPS 1920 x 1080
Battery: Main battery: Li-ion, rechargeable, 8000mAh
Touch Panel: Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
Vibrator: Sound, LED indicator, vibrator
Interfaces: USB Type-C, USB 2.0, OTG
Card Slot: 2 PSAM slots at most (ISO7816 protocol), 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
Keypad: 1 power key, 2 scan keys, 1 multifunctional key, numeric keyboard
Sensors: Light sensor, proximity sensor, gravity sensor
Audio: 1 microphone；1 speaker；receiver

Platform

Operating System: Android 11.0; SafeUEM supported. Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility
Sdk: Chainway Software Development Kit
Language: Java
Tool: Eclipse / Android Studio
Cpu: Cortex-A53 2.5 / 2.3 GHz Octa-core
Ram+Rom: 3GB + 32GB 4GB + 64GB (optional)
Expansion: Supports up to 128 GB Micro SD card

Wireless

Wlan: IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna
Wwan: 2G: GSM850/GSM900/DCS1800/PCS19003G: WCDMA：B1/B2/B4/B5/B8CDMA2000 EVDO: BC0TD-SCDMA：A/F4G:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28AB28B/B34/B38/B39/B40/B41
Bluetooth: Bluetooth 5.0
Vo-Lte: Support Vo-LTE HD video voice call
Gnss: GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Camera

Rear Camera: 13 MP autofocus rear camera with flash

Scanning

2D Scanner: Zebra SE4710, Honeywell N6603, Coas IA166S / IA171S
2D Symbologies: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

Environmental

Operating Temp: -4oF to 122oF / -20 ℃ to +50 ℃
Storage Temp: -40℉ to 158℉ / -40 ℃ to 70 ℃
Humidity: 5% RH – 95% RH non condensing
Drop Specification: Multiple 1.5 m / 4.92 ft. drops to the concrete across the operating temperature range
Tumble Specification: 1000 x 0.5 m / 1.64 ft. falls at room temperature
Sealing: IP65 per IEC sealing specifications
Esd: ±15 KV air discharge, ±8 KV conductive discharge
